Conformal Coating Curing Oven
JCURE-5+
IR Curing Oven – Compact and Efficient Film Coating Solution
jCURE+ Series – Compact IR Curing Ovens
The jCURE-3+, jCURE-4+, and jCURE-5+ models are infrared (IR) curing ovens available in different lengths. With their advanced IR technology, they deliver efficient and consistent curing. A single jCURE+ oven provides the heating length of two conventional ovens (1 jCURE+ = 2 ovens), making it an ideal solution to save space and reduce costs in production environments.
| Feature | JCURE-5+ |
|---|---|
| Length | 4940 mm |
| Width | 1560 mm |
| Height | 1250 mm |
| Weight | 1750 kg |
| No. of heating zones (Top) | 5 |
| Total power | 24.2 kW |
| Feature | JCURE-5+ |
|---|---|
| Conveyor type | Chain conveyor |
| Conveyor height | 900 ± 20 mm |
| Conveyor width | 50 - 460 mm (Auto adjustment) |
| Conveyor clearance | Above: 100 mm; bottom: 100 mm |
| Pin/Chain edge clearance | 5 mm |
| Conveyor speed | 200 - 2000 mm/min |
| Conveyor direction | Left to right (Option: Right to left) |
| Feature | JCURE-5+ |
|---|---|
| Power per IR heating zone | 4.8 kW |
| Heat up time (Stable stage) | 25 - 30 mins |
| Temperature setting range | Room temp. - 200°C |
| Temperature deviation on PCB | ± 5°C |
| Feature | JCURE-5+ |
|---|---|
| Bottom IR heating zones | For top & bottom curing at one go |
| Pallet return conveyor (Underneath) | For OMO concept Reduce manpower Reduce the number of pallets needed |
| Top IR heating zones for underneath pallet return conveyor | For OMO concept Double the curing time OR cure the bottom side |
This product video introduces JTU jCURE+ Series by summarizing its general working principle and typical application scenarios.
