The Energy Saving Nitrogen Cabinet (N2 Cabinet) offers superior protection for moisture-sensitive materials by maintaining an optimal environment with precise humidity control. This nitrogen dry cabinet is equipped with an automatic nitrogen flushing system that detects high humidity levels and activates nitrogen gas to reduce moisture. Once humidity levels reach the set value, the nitrogen flow stops, significantly saving on nitrogen energy.
Key Features Include
✔ Automatic Humidity Control: Detects excess humidity and adjusts nitrogen flow accordingly.
✔ Humidity Alarm: Alerts you if humidity levels deviate from the set range.
✔ RS-232 Interface: Compatible with optional data loggers for temperature and humidity recording.
✔ O2 sensing function (optional): Users can choose to purchase the O2 sensing function based on their needs.
Ideal for laboratory and industrial applications, the Nitrogen Cabinet ensures efficient and effective moisture control, preserving the integrity of sensitive materials.
| Feature | QB-1200-6 | QB-600 | QS-1200-6 | QS-600 |
|---|---|---|---|---|
| Humidity Range | 1~50%RH, adjustable | 1~50%RH, adjustable | 1~50%RH, adjustable | 1~50%RH, adjustable |
| Precision | ±3.0%RH, ±1.0℃ | ±3.0%RH, ±1.0℃ | ±3.0%RH, ±1.0℃ | ±3.0%RH, ±1.0℃ |
| Voltage | 110V/230V | 110V/230V | 110V/230V | |
| External dimensions (mm) | W1200*D672*H1820 | W600*D672*H1820 | W1200*D672*H1820 | W600*D672*H1820 |
| Internal dimensions (mm) | W1198*D644*H1618 | W598*D644*H1618 | W1198*D635*H1647 | W598*D635*H1647 |
| Shelf dimensions (mm) | W1155*D530*H20 | W555*D530*H20 | W1155*D530*H20 | W555*D530*H20 |
| Capacity | 1250L | 624L | 1250L | 624L |
| No. of Shelf | 5 | 5 | 5 | 5 |
| Power consumption | Ave. 20Wh / Max. 50W | Ave. 20Wh / Max. 50W | Ave. 20Wh / Max. 50W | Ave. 20Wh / Max. 50W |
