The Eurostat Stat-Gate calibration tool is designed to calibrate and verify EPA access testers. It includes all components needed to simulate wrist strap and footwear resistances.

Contents:

✓ 1 specific wire for wrist connection

✓ 2 metallised contact electrodes with Jack wires for shoe connection

✓ 1 box with dedicated resistance to calibrate and check the access tester

Calibration ranges:

✓ Wrist: 750kΩ and 35MΩ (±10%)

✓ Shoes: 100kΩ and 100/200MΩ (±10%)

✓ Software utility included for updates

✓ Compatible with all Eurostat Stat-Gate systems

✓ IEC 61340-5-1 compliant
