Rapid H8
The RAPID H8 Horizontal System Bare Board Tester offers the highest performance in terms of throughput and electrical measurements. It is equipped with 8 completely independent measurement probes allowing speeds up to 9000 hits per minute.
With 4 probes on each side, it can carry out accurate measurements on both sides of the PCB. This system allows the execution of every type of test, such as continuity, isolation, Kelvin test, resistive and capacitive measurements as well as active and passive embedded component tests.
The high throughput of this innovative test system facilitates its integration in production lines, using the automated integrated conveyor, an unparalleled tool which can be used to test many different batches of boards to full automation bringing speed, accuracy and versatility to the prototype and production environment.
- The system tests inner layers, ceramic substrates, flexible circuit boards, and printed circuit boards.
- Equipped with 8 independent flying probes.
- Integrated 2 CCD cameras for top and bottom fiducial markers.
- Offers a 540mm x 610mm (21" x 24") test area.
- Performs high voltage and high impedance isolation tests.
- Available with an optional vacuum table.
- Ensures precise probing on small pads and fine pitch components.
- Provides very high speed testing capabilities.
- Embedded repair station software included.
- Features soft touch capabilities.
- Supports in-circuit tests of embedded components.
- Utilizes powerful brushless motors.
- Supports manual and automatic board loading.
- Powered by Seica VIVA® Software.
Through advanced hardware and software integration, the flexible architecture easily addresses all unique market segments. Seica is the only ATE manufacturer providing the RAPID Line with two complementary architectures to satisfy diverse operational and manufacturing process requirements.
The horizontal architecture offers systems designed for in-line configurations, allowing full automation of the testing process and eliminating operator intervention. In the modern market, in-line automation signifies the capability to test dozens of unique batches or board part numbers in small or large quantities, rather than just high-volume production.
An integrated, automated conveyor compliant with SMEMA standards enables in-line deployment or combination with the MTBH loading and unloading module for automatic handling of various board sizes.
Conversely, the vertical systems feature an ergonomic design and a reduced footprint, making them suitable for space-constrained environments where operators can work efficiently. Quick manual loading and unloading procedures, coupled with fast test program turnaround times, ensure precise testing of individual PCBs even during continuous test modifications.
All RAPID testers utilize the Seica VIP platform to deliver high performance and user-friendly operation. Furthermore, optical fiber digital communication keeps signal transmissions completely exempt from interference, which guarantees the maximum accuracy and repeatability of measurements.
