POWERFLOW ULTRA XXL Full-Tunnel Wave Soldering System
POWERFLOW ULTRA XXL
The POWERFLOW ULTRA represents an innovation within the wave soldering portfolio of Ersa GmbH. This full-tunnel wave soldering system is designed to address both current and future demands regarding flexibility and throughput.
The system is available with frame transport as well as finger transport options. Working widths from 330 mm up to 610 mm (XXL version) are supported. It is also suitable for soldering server boards used in 5G communication applications.
| Technical Specification | POWERFLOW ULTRA XXL |
|---|---|
| Length | of 6,450 mm |
| Width | approx. 1,613 m |
| Height | approx. 1,580 mm |
| Transport System | POWERFLOW ULTRA XXL |
|---|---|
| Transport Type | Finger transport, frame transport |
| Max. Transport speed | 2.5 m/min |
| Max. Working width | 610 mm |
| Max. PCB structures up to | 150 mm |
| Preheating/Soldering Module | POWERFLOW ULTRA XXL |
|---|---|
| Preheating length | 2,400 mm |
| Heat transfer | by means of convection, medium-wave radiation and short-wave radiation |
| Individually configurable | - |
| Soldering module | 525 to 800 kg solder content depending on configuration |
