The modular structure ensures easy cleaning and maintenance routines. Engineered with a stable, reliable anti-deformation structure design, the system provides both manual and electric width adjustment options. Front and rear air return configurations effectively isolate airflow between zones, ensuring accurate temperature control. Full nitrogen filling is optional, delivering multi-directional protection for product welding quality. Additionally, the unit can be equipped with an optional nitrogen closed-loop control system to achieve low nitrogen consumption and cost-effective production.
✔ High heat energy: Professional heating power and volume matching ensure a substantial thermal supply, generating optimal thermal efficiency to maximize productivity within short heating zones.
✔ Low energy consumption: Rigorous theoretical design and practical testing yield optimal CPK repeatability values, maintaining minimal energy consumption on the factory floor.
✔ Thermal equalization: Verified performance ensures a minimal heat absorption difference between small and large components at uniform speed and temperature settings, achieving consistent thermal balance.
✔ Large size: Accommodates larger PCB dimensions within the same footprint, supporting dual-track processing up to 300 mm width simultaneously or single-track operation up to 550 mm width.
| Feature | SER-708AH / SER-708H / 5ER-708NH | SER-710AH / SER-710H / SER-710NH | SER-712AH / SER-712H / SER-712NH | SER-706AH |
|---|---|---|---|---|
| Heating zone structure | 8 Heating Zones, 16 Heating moudules | 10 Heating Zones, 20 Heating moudules | 12 Heating Zones, 24 Heating moudules | 6 Heating Zones, 12 Heating moudules |
| Heating zone length | 2950mm | 3670mm | 4350mm | 2230mm |
| Cooling Type | Double cooling:enforced air cooling/water cooling (Optional:three cooling zones) | Double cooling:enforced air cooling/water cooling (Optional:three cooling zones) | Double cooling:enforced air cooling/water cooling (Optional:three cooling zones) | Double cooling:forced air cooling |
| Outlet Exhaust Diameter,valume | 2-Φ145, Exhaust demand 15m³/minx 2 | 2-Φ145, Exhaust demand 15m³/minx 2 | 2-Φ145, Exhaust demand 15m³/minx 2 | 2-Φ145, Exhaust demand 15m³/minx 2 |
| Feature | SER-708AH / SER-708H / 5ER-708NH | SER-710AH / SER-710H / SER-710NH | SER-712AH / SER-712H / SER-712NH | SER-706AH |
|---|---|---|---|---|
| Product Width | min50mm-max400mm | min50mm-max400mm | min50mm-max400mm | min50mm-max400mm |
| Conveying Direction | L→R, R→L | L→R, R→L | L→R, R→L | L→R, R→L |
| inlet Height | 900+20mm | 900+20mm | 900+20mm | 900+20mm |
| Fixed Rail Side | Front rail Fixed(Option: Rear Rail Fixed) | Front rail Fixed(Option: Rear Rail Fixed) | Front rail Fixed(Option: Rear Rail Fixed) | Front rail Fixed(Option: Rear Rail Fixed) |
| Conveyor Type | Chain+mesh belt synchronous transmission | Chain+mesh belt synchronous transmission | Chain+mesh belt synchronous transmission | Chain+mesh belt synchronous transmission |
| Cmponent Height | Clearance based on the rail: above 30mm, below 20mm | Clearance based on the rail: above 30mm, below 20mm | Clearance based on the rail: above 30mm, below 20mm | Clearance based on the rail: above 30mm, below 20mm |
| Conveying Speed | 300mm-1500mm/min | 300mm-1500mm/min | 300mm-1500mm/min | 300mm-1500mm/min |
| Feature | SER-708AH / SER-708H / 5ER-708NH | SER-710AH / SER-710H / SER-710NH | SER-712AH / SER-712H / SER-712NH | SER-706AH |
|---|---|---|---|---|
| Power Supply | AC3Φ, 5W,380V,50/60HZ | AC3Φ, 5W,380V,50/60HZ | AC3Φ, 5W,380V,50/60HZ | AC3Φ, 5W,380V,50/60HZ |
| Total Power | 57KW | 71KW | 89KW | 45KW |
| Start up Power | 30KW | 35KW | 40KW | 30KM |
| Running Power | 7.5KW | 9.5KW | 11.5KW | 6KW |
| Temperature Range | Room temp to 320°C | Room temp to 320°C | Room temp to 320°C | Room temp to 320°C |
| Control Type | PC+PLC Control System | PC+PLC Control System | PC+PLC Control System | PC+PLC Control System |
| Rail Width Adjusting Mode | Electric+Manual | Electric+Manual | Electric+Manual | Electric+Manual |
| Temp Control accuracy | ±1°C | ±1°C | ±1°C | ±1°C |
| PCB Temp Deviation | ±1°C | ±1°C | ±1°C | ±1°C |
| Data Storage | Process Data and status stotage | Process Data and status stotage | Process Data and status stotage | Process Data and status stotage |
| Power Outage Protection | Equipped with UPS | Equipped with UPS | Equipped with UPS | Equipped with UPS |
| Operation Interface | Windows Chinese simplified, English online free switching | Windows Chinese simplified, English online free switching | Windows Chinese simplified, English online free switching | Windows Chinese simplified, English online free switching |
| Feature | SER-708AH / SER-708H / 5ER-708NH | SER-710AH / SER-710H / SER-710NH | SER-712AH / SER-712H / SER-712NH | SER-706AH |
|---|---|---|---|---|
| Dimension (L×W×H) | 5055x1372x1515 | 5775x1372x1515 | 6495x1372x1515 | 4335x1372x1515 |
| Weight | 2000-2200kg | 2400-2600kg | 2800-3000kg | 1600-1800kg |
| Color | Bright wrinkled white | Bright wrinkled white | Bright wrinkled white | Bright wrinkled white |
This product video introduces SER-708AH by summarizing its general working principle and typical application scenarios.
