NC275B No Clean Liquid Flux
NC275B VOC-Free Water-Based No Clean Fluxoutperforms competing alcohol-based liquid fluxes in wave soldering processes. NC275B’s superior wetting performance and electrochemical reliability make it an ideal chemistry for most applications.
NC275B’s halogen-free/VOC-free formulation is environmentally friendly without compromising activity.
NC275B flux residue is compatible with AIM’s line of no clean chemistries including solder paste, cored solder wire, and rework fluxes.
✔ Water-Based/VOC-Free
✔ Zero-Halide/Halogen
✔ High Activity
✔ ORL0 per J-STD-004*
✔ Medium Post Process Residues
✔ REACH Compliant
✔ Designed for spray flux application
✔ Water-based chemistry contains no flammable solvent
✔ High activity promotes barrel-fill with all lead-free alloys
✔ No clean: post-reflow residues are safe to leave on the assembly
✔ Environmentally friendly formulation: halogen-free/VOC-free
| Flux Type | Applications | Application Method | Alloy Compatibility |
|---|---|---|---|
| ORL0 | Wave | Spray Convection Pre-Heat | Pb and PB-Free |
