ROSİN LQUID FLUX
ROSİN LQUID FLUX
ROSİN LQUID FLUX
RMA202-25 Rosin Liquid Flux
RMA202-25 is a high-solids mildly activated liquid rosin flux developed for high reliability soldering applications.
RMA202-25 proprietary activator system provides a wide process window, excellent thermal transfer, and powerful wetting with both lead-free and leaded assemblies.
RMA202-25 leaves a post-process flux residue that is both non-corrosive and non-conductive and does not require removal.
✔ Rosin Mildly Activated (RMA)
✔ Residues Removable with a Saponifer or Solvent
✔ Can be Foamed, Sprayed, Dipped or Brushed
✔ ROL0 per J-STD-004
✔ Non-Corrosive/Non-Conductive Residue
✔ IPC-A-610F Class 3 Compliant
✔ Military/High Reliability Applications
✔ High SIR values appropriate for automotive, medical, and military applications
✔ Flux residues are safe on the board after soldering
• When cleaning is required, residues can be removed via vapor degreasing, solvent cleaners, and aqueous cleaners
✔ Medium solids
✔ Powerful wetting promotes full barrel-fill
✔ Compatible with all AIM RMA fluxes
| Flux Type | Applications | Application Method | Alloy Compatibility |
|---|---|---|---|
| ROL0 | Wave/Selective Soldering Dipping Tinning Rework | Spray or Foam Fluxer Brushed Dipped | Pb and PB-Free |
