MFR-1110 Single Output Soldering & Rework System
MFR Single Port System, Soldering Cartridge
The MFR-1100 Single Output Series is engineered to minimize training investments, maximize application solutions, and significantly boost productivity. This compact and versatile series is compatible with a soldering tip, cartridge, or tweezer handpiece. Additionally, a shop air desoldering option is available as an upgrade kit to enhance functionality.
SmartHeat® Technology provides exceptional power for high thermal demand applications. Single or dual simultaneous outputs allow for single or dual hand-piece use. Five hand-pieces are available for increased application solutions regarding soldering, de-soldering via the MX-UK5 upgrade kit, and rework on one system. Furthermore, each hand-piece has a comprehensive range of cartridges or tips for maximum flexibility. Ergonomic handpieces ensure operator safety and comfort.
Product Comprise of
✔ MFR-PS1100 Soldering Station
✔ MFR-H1-SC2 Hand-Piece
✔ WS1 Workstand
| Feature | MFR-1110 |
|---|---|
| Input Line Voltage | 100 - 240 VAC, grounded circuit, 50/60 Hz |
| Rated Power Consumption | 70 W max. |
| Output Power | Variable, 60 W max.* |
| Output Frequency | 450 KHz |
| Heating Method | Induction, SmartHeat® |
| Connections | Single Port |
| Power Supply Dim. W x D x H | 90 x 200 x 152.5 mm (3.5" x 7.9" x 6") |
| Power Supply Weight | 2.3 kg (5.05 lb) |
| Certification / Marking | cTUVus, CE |
| Tip-to- Ground Potential | < 2 mV |
| Tip-to-Ground Resistance | < 2 Ohm |
| Ground Detection | Permanent |
| Surface Resistivity | 10⁵ - 10⁹ Ohm |
| Idle Temperature Stability | 1.1 °C ( 2 °F) in still air |
| Tip Temperature Accuracy | Meets or exceeds IPC J-STD-001 Standard |
| Power Cord Length | 183 cm, 18/3 SJT |
| Warranty | 1 year |
| Ambient Operating Temp | 10 - 40 °C (50 - 104 °F) |
| Max. Enclosure Temp | 55 °C (131 °F) |
| Solder-Pen Specification | |
| Hand-Piece Cable Length | 122 cm (48”), burn proof, ESD-safe |
| Hand-Piece - RF Connector | 8-pin circular DIN |
This product video introduces MFR-1110 by summarizing its general working principle and typical application scenarios.
