Inline and Batch Selective Soldering System Delivering Top Soldering Quality
ECO SELECT 4
The ECOSELECT 4 is a compact solution designed for small to medium production runs where flexibility is key. Incorporating advanced machine technology from the latest VERSAFLOW generation, it features a high-quality roller conveyor for PCBs up to 508 x 508 mm. Suitable for both batch and inline operation, the system also includes power convection for uniform and reliable heating, even with challenging components.
| Technical Specification | ECO SELECT 4 |
|---|---|
| Length | 2,000 mm |
| Width | 1,800 mm |
| Height | 1,700 mm |
| Conveyor System | ECO SELECT 4 |
|---|---|
| Conveyor Type | Roller transport |
| PCB width | 50-508 mm |
| PCB length | 127-508 mm |
| Max. PCB superstructures top | up to 120 mm |
| Max. PCB superstructures at the bottom | up to 60 mm |
| Max. PCB weight | 15 kg |
| Fluxer/Preheating/Soldering Module | ECO SELECT 4 |
|---|---|
| Fluxer | Drop jet in various sizes |
| Preheating | IR radiation heating at the bottom, convection at the top (optional), power convection at the top (optional) |
| Soldering module | Electromagnetic soldering pots, Mini wave 13 kg, up to 2 pots |
This product video introduces ECO SELECT 4 by summarizing its general working principle and typical application scenarios.
