Compact Selective Soldering System with Advanced Technology for Universal Applications
VERSAFLOW 3/35
Built on stable processes and reproducible parameters, Ersa selective soldering solutions deliver top performance in quality, cost efficiency, and delivery reliability. The VERSAFLOW 3/35, featuring fluxing, preheating, and soldering modules with a segmented conveyor system, comes fully equipped with all essential options to meet future production requirements.
| Technical Specification | VERSAFLOW 3/35 |
|---|---|
| Length | 2,450 mm (basic machine) |
| Width | 1,750 mm |
| Height | 1,650 mm |
| Conveyor System | VERSAFLOW 3/35 |
|---|---|
| Conveyor Type | Pin chain conveyor or roller conveyor |
| PCB width | 60-508 mm |
| PCB length | 120-508 mm (opt. 600 mm) |
| Fluxer/Preheating/Soldering Module | VERSAFLOW 3/35 |
|---|---|
| Fluxer | Drop-Jet 130 µm stainless steel |
| Preheating | combination of IR and convection |
| Soldering module | electromagnetic soldering pots |
