Selective Soldering Technology with Maximum Flexibility and Premium Quality
VERSAFLOW 4/55
The VERSAFLOW 4/55 stands as the pinnacle of Ersa’s inline selective soldering technology, delivering unmatched performance and adaptability. With its flexible modular architecture, enhanced process control, and the award-winning ERSASOFT 5 user interface, it combines ease of operation with industry-leading capabilities.
Featuring VERSAFLUX and VERSAFLEX, it achieves the highest soldering precision for both high-volume, low-change production (Low Mix, High Volume) and high-mix, low-volume manufacturing scenarios. Nearly unlimited configuration options allow the VERSAFLOW 4/55 to be tailored precisely to each customer’s needs. For maximum adaptability, the Flex module enables rapid changeovers, while the XL version is engineered for extra-large PCBs, making it the ultimate choice for demanding electronics manufacturing.
| Technical Specification | VERSAFLOW 4/55 |
|---|---|
| Length | from 2.600 mm |
| Width | approx. 1.800 mm |
| Height | approx. 1.600 mm |
| Conveyor System | VERSAFLOW 4/55 |
|---|---|
| Conveyor Type | Roller conveyor |
| PCB width | 63.5-508 mm |
| PCB length | 127-508 mm |
| Max. PCB superstructures top | up to 120 mm |
| Max. PCB superstructures at the bottom | up to 60 mm |
| Max. PCB weight | 5 kg (opt. 15 kg) |
| Fluxer/Preheating/Soldering Module | VERSAFLOW 4/55 |
|---|---|
| Fluxer | Drop jet in various sizes |
| Preheating | IR radiator heating, convection or combination of IR and convection |
| Soldering module | Electromagnetic pot, Mini wave 13 kg up to 6 pots |
This product video introduces VERSAFLOW 4/55 by summarizing its general working principle and typical application scenarios.
